Case Study 1 — QNAP TS-233 (Accidental LUN Deletion + New LUN Created)

Client: Financial services (bank)
Appliance: QNAP TS-233 (QTS, ext4 volume, 2-bay)
Reported issue: iSCSI LUN deleted in error; a new LUN created afterwards on the same volume. Previous vendor(s) and OEM unable to assist.

Triage & Risk

• File-based iSCSI LUNs on QTS sit as sparse files on an mdadm → LVM → ext4 stack.

• Creating a new LUN can overwrite unallocated extents previously belonging to the deleted LUN. Priority is to stop all writes and acquire block-level clones of every member disk.

Lab Workflow (Forensic)

1. Member imaging (read-only):

   • Hardware imagers with timeout budgeting, per-head zoning on HDDs (if present), ECC-aware passes.

   • Verified with per-image SHA-256.

2. Virtual rebuild of the QNAP storage stack:

   • Parse mdadm superblocks and assemble virtual RAID from clones (no writes to originals).

   • Reconstruct LVM PV/VG/LV geometry.

   • Mount the ext4 volume read-only (disable journal replay).

3. Recover the deleted LUN container:

   • Extent-level scan of ext4 inode/extent trees and journal to locate the orphaned LUN’s sparse-file metadata remnants.

   • Where inode records were purged, derive a synthetic file by mapping the LUN’s physical extents from allocation bitmaps and historical journal entries.

   • Validate by searching for embedded filesystem signatures inside candidate ranges (NTFS boot sectors / VMFS headers / partition tables) to confirm correct contiguity.

4. LUN content extraction:

   • Present the reconstructed LUN as a virtual block device; repair the guest filesystem (NTFS/VMFS/ext) on the clone only using journal-aware methods (e.g., NTFS $LogFile replay, MFT mirror).

   • Fill small gaps (where the new LUN overwrote blocks) using structure-aware carving and application-level validation (e.g., PST/DB headers, video container indices).

5. Verification & hand-off:

   • File-level hashing and sample validation across business-critical datasets.

   • Delivery via encrypted transfer drive.

Outcome: 100% data set restored for the bank’s scope of work (no material gaps detected; new-LUN overlap did not intersect live data ranges).

Case Study 2 — Synology DS1522+ (Three Failed Disks After User Swap)

Client: SME design studio
Appliance: Synology DS1522+ (Ryzen R1600), SHR-2 (RAID-6) with Btrfs
Reported issue: Three disks reported failed; user swapped drives; an automatic rebuild likely started; NAS no longer boots cleanly.

Triage & Risk

• SHR-2 tolerates two concurrent failures; a third fault plus a partial rebuild can leave divergent metadata epochs and parity contamination.

• Some “failed” disks are often intermittently readable; correct approach is donor-assisted imaging, then virtual reconstruction of the pre-incident epoch.

Lab Workflow (Forensic + Mechanical)

1. HDD stabilisation & imaging:

   • Two drives imaged with adaptive head-map strategies; the third required head-stack replacement (donor matched by model/firmware/micro-jog; ROM adaptives verified).

   • Multi-pass imaging with short-retry windows and thermal rest cycles; per-clone SHA-256.

2. Rebuild the Synology stack (virtual):

   • Recover mdadm layer(s) from superblocks; select a consistent event count (pre-rebuild) across members.

   • Assemble Btrfs chunk/stripe map; choose the best superblock pair; reconstruct the root tree and subvolume metadata.

3. Parity & epoch conflict resolution:

   • Identify stripes affected during the short rebuild window; majority vote of blocks or exclude contaminated extents using Btrfs checksum guidance.

   • Validate by walking file trees and confirming checksum-good data blocks.

4. Export & verification:

   • Snapshot-consistent export of the primary share sets; per-file hashing; targeted open-in-app tests for project files (Adobe suites, large media).

Outcome: Full recovery of active project shares and archives. NAS returned to client with guidance to rebuild onto new media; original failed disks retained as evidence.

Case Study 3 — MacBook Air 13″ (M1, 2020) Booting to Recovery

Client: Individual professional
Platform: Apple silicon M1; soldered NVMe NAND with SEP-bound (Secure Enclave) keys; APFS with FileVault commonly enabled
Reported issue: Device boots to macOS Recovery/Utilities; user cannot access data.

Note (accuracy): On Apple silicon there is no removable SSD. Traditional “chip-off” is ineffective because the encryption keys are hardware-bound to the Secure Enclave. Correct methodology is board-level stabilisation and credentialed, SEP-assisted imaging/decryption.

Lab Workflow (Board-Level + Logical)

1. Stabilise logic board power & boot path:

   • Rail checks (PPBUS, PP3V3_S5, etc.), PMIC inspection; resolve an intermittent TB/USB-C path affecting Share Disk.

   • Enter 1 True Recovery (1TR) / DFU; perform Revive (not Restore) to preserve user data.

2. Credentialed acquisition:

   • With the client’s passcode/FileVault credentials, unlock the APFS keybag.

   • Acquire a read-only block image over TB (Share Disk) or via asr to a lab target, ensuring no APFS snapshot deletion.

3. APFS repair on the image (not the Mac):

   • Walk checkpoint superblocks; rebuild the Object Map (omap) and volume structures; mount Data volume read-only.

   • Validate and export user data; repair per-app stores (Photos library, Mail, Notes) as needed.

4. Verification & delivery:

   • Sample-open critical documents; per-file hashes; deliver on encrypted media.

Outcome: 100% data recovery. Device boot issue left unmodified (client elected for Apple service after data hand-off). No Activation Lock bypass; all work conducted with client’s credentials.

Shared Engineering Principles (All Cases)

• Forensic-first: Originals are never modified; we work from verified clones.

• Minimal necessary intervention: Mechanical or micro-soldering only to the extent required to enable safe imaging.

• Stack-accurate reconstruction: We rebuild exact storage stacks (controller/NAS → md/LVM → FS → LUN/VMFS) virtually, then repair on the image.

• Integrity checks: SHA-256 at image and file level; sample validation in native applications.

• Clear limits: Truly overwritten blocks or cryptography without valid keys are not recoverable; we maximise outcomes via journals, snapshots, replicas and structure-aware methods.
